Burning solids, such as paper, wood, fibres & plastics.
Water, the best fire extinguisher suited for combating fires involving ordinary carbonaceous materials like wood, paper, cloth, rubber jute. Water extinguishes fire rapidly by striking, instant cooling <& quenching effects.
SPECIAL FEATURES
Capacity
9 lits.
50 lits.
135 lits.
Jet range (in mtrs)
6
10
20
jet maintain for min - sec.
60
60
90
discharge time -sec.
60-120
60-180
60-180
minimum % of discharge
9.5
95
95
empty weight in kg.
5.5
34
96
full weight in kg.
14.5
84
231
SUITABLE FOR CLASSES "A" & "B" FIRES
Burning solids, such as paper, wood, fibres, plastics & Oil, Kerosene, Petrol etc.
This extinguisher forms a thick layer of foam over the burning surface, effectively cutting of atmospheric supply of oxygen to the burning surface thereby smothering the fire and preventing re-ignition. Foam extinguishes fire by giving blanketing effect.
SPECIAL FEATURES
Capacity
9 lits.
50 lits.
135 lits.
Jet range (in mtrs)
6
10
16
jet maintain for min - sec.
25
60
60
discharge time -sec.
25-90
60-180
60-180
minimum % of discharge
90
90
90
empty weight in kg.
5.5
34
96
full weight in kg.
14.5
84
231
TECHNICAL SPECIFICATION
As per IS Specification & Capacity:
Water Co cap.9Itrs. as per IS Spec' 940 & 50 Itrs
AFFF Mechanical Foam as per IS Spec 10204 9 Itrs & 50 Itrs. per IS: 13386
Construction :
BodyCRCASheelslS.513
Cap
Gun metal / forging
Anti- Corrosive treatment
Body coated with epoxy powder coating / phosphiatised
Hydraulic test
Carried out at 30 kg/cm as per IS norms
Charge
AFFF/Clean Water & Co gas cartridge is fixed with each extinguisher.
Finish
Fire Red Epoxy polyester powder coatinq/Painted in Synthetic enamel fire red.
Accessories
Wall mounting brackets (Higher capacity is wheel mounted)
Maintenance
The fire extinguisher must be maintained as per IS:2190 for satisfactory, Performance.
Operation
Keep the AGNIMAN extinguisher uprigtl.Remove the safety clip <& strike the knob Direct discharge to fall on the base of the fire
FOAM(AFFF) AND WATER EXTINGUISHERS ARE ALSO AVAILABLE IN STORED PRESSURE/SQUEEZE GRIP
