ABC Stored Pressure



SUITABLE FOR CLASSES "A" "B" & "C" FIRES

Burning solid such as paper, wood, fibres, plastics & burning gases such as butane, chloride & natural propane, vinyl chloride & natural gases. Live electrical equipment.



This is a premium range of appliances available in ABC powder, pressurised with dry nitrogen gas. The contents are expelled by the release of pressure stored inside the body. The inbuilt pressure gauge indicates its readiness for use. ABC powder is one of the most versatile and highly effective agents suitable to combat fires involving wood, inflammable liquids, gases and electrical wiring. This extinguisher knocks down fire by beating and displacement of air

SPECIAL FEATURES

Capacity

1 kgs.

2 kgs. 5kgs. 10 kgs.

Jet range (in mtrs)

 4 4 4 4

jet maintain for min - sec.

 6 6 15 15

discharge time -sec.

 6-12 6-12 15-25 15-25

minimum % of discharge

 85 85 85 85

empty weight in kg.

 1.2 1.5 4 7
full weight in kg. 2.2 3.5 9 17

TECHNICAL SPECIFICATION
Capacity:

5OOgms, 1kg, 2kgs, 5kgs, 10kgs.
Construction :

Manufactured out of CRCA sheets in all welded construction.
Valve

Brass forged/gun metal.
Hydraulic test

30kgf/cm'
Charge Pressure

<=15kgf/cm'
Charge

Dry Powder MONO AMMONIUM PHOSPHATE base
Finish

Epoxy polyster powder coated
Accessories

Wall mounting brackets.
Maintenance

The AGNIMAN fire extinguisher must be maintained as per IS: 2190 for satisfactory performance.
Operation

Pull out safety pin, detach hose from the bracket, squeeze the lever and aim the jet at the base of fire in a sweepingmotion.
